Techna’s Htec DC 10kA Miniature Circuit Breakers (MCBs) allow usage on DC circuits up to 250 Vdc in a single pole and 500 Vdc with two poles in series configuration. The Htec DC 10kA MCB range are polarity sensitive so must be wired correctly.
Our range of Htec DC 10kA MCBs are available in 1 or 2 pole, in a wide range of current ratings from 1A to 63A and are offered in trip curves B and C. We also have add-on Shunt Trip Modules and Auxiliary Contacts available for our Htec DC Series MCBs.
The Htec DC miniature circuit breakers are suitable for mounting on DIN-Rail and can also be used inside our Dtec Circuit Breaker Enclosures and our WINtec IP67 Circuit Breaker Inspection/Protection Windows.
Htec DC 10kA MCBs Technical Specification
• Breaking Capacity: 10kA
• Number of Poles: 1 or 2
• Current Range: 1A - 63A
• Rated Voltage DC: 250 Vdc (Single Pole), 500 Vdc (Double Pole in Series)
• Trip Curves: B and C
• Impulse Withstand Voltge: 6.2kV
• Frequency Range: 50Hz - 60Hz
• Mounting: DIN-Rail
• Electrical Life: 6,000 Switching Operations
• Mechanical Life: 10,000 Switching Operations
• Screw Terminal: M5
• Terminal Tightening Torque: 2Nm
• Standards: IEC 60898-2
Htec DC 10kA MCBs Accessories
We also offer various accessories for our range of Htec DC 10kA miniature circuit breakers, such as add-on Htec Shunt Trip Modules available in 24Vac/dc, 110Vac/dc and 230Vac/dc and add-on Htec Auxiliary Contacts available as either a 1 Changeover or Signal Changeover.
-
